Description
Economic Electric Forklift Trucks Semi-Electric Hydraulic Pallet Stackers
EPM series
■ Electric lifting and manual moving, can be used as a economic forklift truck for stacking pallets.
■ Precise lifting and lowering via hand lever.
■ With high quality lift pump station.
■ Integrated 100AH maintenance free battery.
■ Option adjustable forks for wider applications.
■ Conforms to EN1757-2.
■ With key switch, emergency button, and coulombmeter in control panel.
| Model | EPM1016 | EPM1025 | EPM1030 | EPM1033 | |
| EPM1516 | EPM1525 | EPM1530 | EPM1533 | ||
| Capacity | (kg) | 1000 | |||
| 1500 | |||||
| Min. Fork Height | (mm) | 90 | |||
| Max. Fork Height | (mm) | 1600 | 2500 | 3000 | 3300 |
| Fork Length | (mm) | 1150 | |||
| Overall Forks Width | (mm) | 560 | |||
| Individual Fork Wdith | (mm) | 160 | |||
| Load Center | (mm) | 600 | |||
| Overall Length | (mm) | 1770 | |||
| Overall Width | (mm) | 700 | |||
| Overall Height | (mm) | 2020 | 1770 | 2020 | 2170 |
| Front Wheel Diameter | (mm) | 80 | |||
| Rear Wheel Diameter | (mm) | 200 | |||
| Lift Motor | (kw) | 1.6 | |||
| Battery Capacity | (V/Ah) | 12/100 | |||
| Net Weight | (kg) | 286 | 367 | 387 | 400 |
| 310 | 392 | 413 | 433 | ||
