Forklift Truck Maintenance Hydraulic Jack
HFJ series
■ Specially designed for forklift truck maintenance, Max. lifting capacity 4000kg, 5000kg, and 7000kg.
■ HFJ-500 has two alternative lifting positions, Low position with capacity 4000kg, High position with capacity 5000kg.
■ Uniquely built in two Lifting Speeds, quick lifting and slow lifting which can be automatically switched between with load and without load.
■ Quick lifting - 20 times pump strokes, slow lifting - 60 times pump strokes.
■ Built in overload valve and bypass valve.
■ Guarantees safety and reliable operation.
■ Low profile height 65mm.
■ High capacity and rugged construction.
■ Extra low pick up point and 2-position lift pad for hard-to reach places under low profile lift trucks.
■ Special designed hydraulic pump with high quality seal kits and overload valve.
■ Removable handle and compact size.
■ Meets CE standard and ANSI standard.
| Model | HFJ-400 | HFJ-700 | HFJ-500 | ||
| Lifting Position | Low position | Low position | Low position | High position | |
| Rated Capacity | (kg) | 4000 | 7000 | 4000 | 5000 |
| Min. Height | (mm) | 65 | 65 | 65 | 416 |
| Max. Height | (mm) | 406 | 420 | 425 | 724 |
| Width | (mm) | 203 | 250 | 210 | |
| Net Weight | (kg) | 33 | 49 | 45 | |
