Description
Aluminium Mono Mast Synchronous Belt Structure Electric Work Positioners
MES series
■ Upgraded version for E100/E150.
■ Aluminium mono mast offers a good view and light weight to operate.
■ Synchronous belt structure offers a stable lifting and descending, and low noise transmission system.
■ Lifting capacity is from 100/150kg to 180/200kg.
■ 1800mm/2000mm maximuim lifting height is available as option.
■ Desiged with 4 castors and rear steering castors with brake is standard, integrated brake unit as option.
■ Big handle for easy operation.
■ Battery inside and build-on-board charger.
■ PVC platform as standard, and quick change attachment options available.
■ Conforms to EN1757 and EN 1175-1.
| Model | MES100 | MES150 | MES180 | MES200 | |
| Load Capacity | (kg) | 100 | 150 | 180 | 200 |
| Load Centre | (mm) | 235 | 200 | ||
| Maximum Platform Height | (mm) | 1700 | 1500 | 1700 | 1500 |
| Minimum Platform Height | (mm) | 130 | |||
| Platform Size DxW | (mm) | 475x605(PVC) | |||
| Load Roller Size Dia.xW | (mm) | Φ75x20(PU) | |||
| Steering Wheel Size Dia.xW | (mm) | Φ100x32(PU) | |||
| Lifting/Descending Speed | (mm/s) | 55 | |||
| Battery | (V/Ah) | 2x12/10 | |||
| Charger | (V/A) | 24/2 | |||
| Overall Dimensions LxWxH | (mm) | 855x605x2150 | 855x605x1950 | 855x605x2150 | 855x605x1950 |
| Net Weight | (kg) | 60 | 59 | 75 | 74 |
