Description
Single Fork Mini Hydraulic Pallet Lifter
Model SYPG50
■ Ideal transport aid for application in small area, such as school, hospital, convenience store, chapel, and so on.
■ For moving and transporting display pallets, fruit pallets, etc...
■ Single fork for narrow pallets, hydraulic hand type lifting, with balance castors.
■ Simple to be operated by single people.
■With load backrest as option.
| Model | SYPG50 | |
| Capacity | (kg) | 500 |
| Min. Fork Height | (mm) | 85 |
| Max. Fork Height | (mm) | 300 |
| Fork Size(LxWxH) | (mm) | 650x160x55 |
| Overall Length | (mm) | 930 |
| Overall Width | (mm) | 510 |
| Overall Height | (mm) | 1170 |
| Turning Radius | (mm) | 830 |
| Loading Wheel Size | (mm) | Dia.80x60 |
| Net Weight | (kg) | 38 |
