Description
Single Mast Hydraulic Hand Lift Stacker
Model SU1017
■ Mono mast offers a good view for operator.
■ Designed for heavy-duty, intensive and commercial use.
■ Forced synchronous steering on one steering wheel by draw bar.
■ Ergonomically designed handle for simple and comfortable operation.
■ Meshes protect operator from the lifting chain.
■ With quick-lift function as standard.
■ Equiped with polyurethane steering wheels and load rollers, to protect your floor.
■ Conforms to EN1757-1.
| Model | SU1017 | |
| Capacity | (kg) | 1000 |
| Min. Fork Height | (mm) | 88 |
| Max. Fork Height | (mm) | 1700 |
| Fork Length | (mm) | 1150 |
| Overall Forks Width | (mm) | 540 |
| Overall Length | (mm) | 1615 |
| Overall Width | (mm) | 685 |
| Overall Height | (mm) | 2130 |
| Net Weight | (kg) | 245 |
